Driver Seats

All Grammer seats are optimally designed to attenuate the vibrations to which forklift operators are typically subjected, featuring suspension travel of 60 mm. They are also simple to set to any user weight between 50 and 130 kg with an easy-to-use lever on the backrest, resulting in optimal suspension comfort for every operator. In addition, the seats fore-aft position can be varied by up to 150 mm to provide enough space for every body size and work situation. The narrow version with a cushion width of 410 mm is specially optimized for reach-type forklift trucks.

This seats reduced-travel pneumatic suspension, which runs on a 12 V or 24 V power source, effectively attenuates vibrations in even the tiniest cabs. It can be optimally set to the operators weight using an ergonomically placed pushbutton, aided by an indicator.

Grammer mechanical forklift seat with suspension with 80 mm of travel features an easily accessible ratcheting handle for optimal adjustment to the drivers weight. Safe, ergonomic sitting is also ideally enabled by a comfortable, 470-mm-wide seat cushion and mechanical lumbar support.

Including weight and backrest adjustment, Dimensions (W x H x L): 485 x 485 x 500 mm

Including weight and backrest adjustment, Dimensions (W x H x L): 485 x 485 x 500 mm

In vehicles with a low resonant frequency, seats with a low-frequency suspension maximize comfort by absorbing vertical vibrations and jolts. This prevents bouncing as a result of resonance build-up. The lower the suspensions resonant frequency, the greater the comfort experienced by the driver.
